IP Video Intercom

  • ER010BTW

    ER010BTW

    •  Flash: 128MB
    •  RAM: 512MB
    •  Operating system: Linux operation system
    •  Display screen: 10.1″ colorful screen
    •  Display resolution: 1024×600
    •  Operation method: Touch screen
    •  Audio input: Built-in omnidirectional microphone
    •  Audio output: Built-in loudspeaker
    •  Audio compression standard: G.711U
    •  Audio compression rate: 64Kbps
    •  Audio quality: Noise suppression and echo cancellation
    •  Network protocol: TCP/IP, RTSP, SIP
    •  Built-in wifi: 2.4G 802.11 b/g/n
    •  I/O output: NO unlock
    •  Micro SD card: Max to 128GB, SD 2.0 or lower version
    •  Power supply: POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A
    •  Power consumption: 8W(Max), 3W(Standby)
    •  Ringbell: NO (MAX AC/DC36V 4A)
    •  Support pixels: Mainstream: Max 5MP 25FPS camera, Substream: Max 1MP 30FPS camera
    •  Video compression standard: H.265 (default), H264
    •  Working temperature: -10℃-50℃
    •  Working humidity: 10%-90%
    •  Dimensions: 255x180x21mm

    Product details

    Memory 10.1″ video door phone with touch screen

    IP Video Intercom System

    Quad video recording

    Support 8 panels or cameras view

    Human detection

    Powerful smart mobile APP talk & unlock

    Support ONVIF IP cameras

    Monitoring of video door bell or CCTV from mobile APP

    Push notifications

    Customize UI & Melody & Voice message

    Button light background

    Support max.128GB SD Card & flash max.100pcs picture

    Lock control / Calendar / Alarm clock / No disturb

    Simple DVR motion detection / Photo frame / Multimedia manager

    Auto leave message function

    Wi-Fi 802.11b/g/n

    POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A (Optional)

  • ER015BTW

    ER015BTW

    Customize UI & Melody & Voice message, Simple DVR motion detection/Photo frame/Multimedia manager, Wi-Fi 802.11b/g/n, POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A,1080P 8″ colorful screen

     Flash: 128MB

     RAM: 128MB

     Operating system: Linux operation system

     Display screen: 8″ IPS screen

     Display resolution: 1280×800

     Operation method: Touch screen

     Audio input: Built-in omnidirectional microphone

     Audio output: Built-in loudspeaker

     Audio compression standard: G.711U

     Audio compression rate: 64Kbps

     Audio quality: Noise suppression and echo cancellation

     Network protocol: TCP/IP, RTSP, SIP

     Wifi: 2.4G&5G

     Micro SD card: Max to 512GB SD

     Power supply:POE IEEE 802.3AF;DC12-15V,7W;AC100-240V,50/60Hz

     Power consumption: 8W(Max), 3W(Standby)

     Ringbell: NO (MAX AC/DC36V 4A)

     Support pixels: Mainstream: Max 5MP 25FPS camera, Substream: Max 1MP 30FPS camera

     Video compression standard: H.265 (default), H264

     Working temperature: 0℃-50℃

     Working humidity: 10%-90%

     Dimensions:  200x149x23.5mm



    PRODUCT DETAIL

    1080P 8″ video door phone

    IPS 1280*800

    IP Video Intercom System

    Quad video recording

    Support 8 panels or cameras view

    Human detection

    Powerful smart mobile APP talk & unlock

    Support ONVIF IP cameras

    Monitoring of video door bell or CCTV from mobile APP

    Push notifications

    Customize UI & Melody & Voice message

    Button light background

    Support max.512GB SD Card

    Lock control / Calendar / Alarm clock / No disturb

    Simple DVR motion detection / Photo frame / Multimedia manager

    Auto leave message function

    POE IEEE 802.3AF;DC12-15V,7W;AC100-240V,50/60Hz

  • ER009BTW

    ER009BTW

    Customize UI & Melody & Voice message, Simple DVR motion detection/Photo frame/Multimedia manager, Wi-Fi 802.11 a/b/g/n, POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A

    •  Flash: 128MB
    •  RAM: 128MB
    •  Operating system: Linux operation system
    •  Display screen: 7″ colorful screen
    •  Display resolution: 1024×600
    •  Operation method: Touch screen
    •  Audio input: Built-in omnidirectional microphone
    •  Audio output: Built-in loudspeaker
    •  Audio compression standard: G.711U
    •  Audio compression rate: 64Kbps
    •  Audio quality: Noise suppression and echo cancellation
    •  Network Interface: 10M / 100M adaptive + 10M / 100M adaptive belt POE
    •  Network protocol: TCP/IP, RTSP, SIP
    •  Built-in wifi: 2.4G&5G
    •  Micro SD card: Max to 128GB, SD 2.0 or lower version
    •  Power supply: POE IEEE 802.3AF; DC12-15V,7W; AC100-240V,50/60Hz
    •  Ringbell: NO (MAX AC/DC36V 4A)
    •  Support pixels: Mainstream: Max 5MP 25FPS camera, Substream: Max 1MP 30FPS camera
    •  Video compression standard: H.265 (default), H264
    •  Working temperature: 0℃-50℃
    •  Working humidity: 10%-90%
    •  Dimensions: 215x126x20m



    PRODUCT DETAIL

    1080P 7″ video door phone with touch buttons

    HD IPS screen 1024*600 & HD glass

    IP Video Intercom System

    Quad video recording

    Support 8 panels or cameras view

    Human detection

    Powerful smart mobile APP talk & unlock

    Support ONVIF IP cameras

    Monitoring of video door bell or CCTV from mobile APP

    Push notifications

    Customize UI & Melody & Voice message

    Button light background

    Support max.512GB SD Card

    Lock control / Calendar / Alarm clock / No disturb

    Simple DVR motion detection / Photo frame / Multimedia manager

    Auto leave message function

    Built in Wi-Fi: 2.4G&5G

    POE IEEE 802.3AF; DC12-15V,7W; AC100-240V,50/60Hz

  • ER012BTW

    ER012BTW

    Customize UI & Melody & Voice message, Simple DVR motion detection/Photo frame/Multimedia manager, Wi-Fi 802.11b/g/n, POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A

    •  Flash: 128MB
    •  RAM: 512MB
    •  Operating system: Linux operation system
    •  Display screen: 7″ colorful screen
    •  Display resolution: 1024×600
    •  Operation method: Touch screen
    •  Audio input: Built-in omnidirectional microphone
    •  Audio output: Built-in loudspeaker
    •  Audio compression standard: G.711U
    •  Audio compression rate: 64Kbps
    •  Audio quality: Noise suppression and echo cancellation
    •  Network protocol: TCP/IP, RTSP, SIP
    •  Built-in wifi: 2.4G 802.11 b/g/n
    •  Micro SD card: Max to 128GB, SD 2.0 or lower version
    •  Power supply: POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A
    •  Power consumption: 8W(Max), 3W(Standby)
    •  Ringbell: NO (MAX AC/DC36V 4A)
    •  Support pixels: Mainstream: Max 5MP 25FPS camera, Substream: Max 1MP 30FPS camera
    •  Video compression standard: H.265 (default), H264
    •  Working temperature: -10℃-50℃
    •  Working humidity: 10%-90%
    •  Dimensions: 188x136x22mm



    PRODUCT DETAIL

    1080P 7″ video door phone with touch buttons

    HD screen 1024*600

    IP Video Intercom System

    Quad video recording

    Support 8 panels or cameras view

    Human detection

    Powerful smart mobile APP talk & unlock

    Support ONVIF IP cameras

    Monitoring of video door bell or CCTV from mobile APP

    Push notifications

    Customize UI & Melody & Voice message

    Button light background

    Support max.128GB SD Card & flash max.100pcs picture

    Lock control / Calendar / Alarm clock / No disturb

    Simple DVR motion detection / Photo frame / Multimedia manager

    Auto leave message function

    Wi-Fi 802.11b/g/n

    POE IEEE 802.3af / AC100-240V 50/60Hz / DC15V/0.8A (Optional)
